ELECTRICAL RATINGS:
Sea Level @ 28VDC or 115VAC, 60/400Hz
Resistive 5A 4A
Electrical Life: 25,000 cycles 5A @ 28VDC resistive snap-action
Mechanical Life: 1,000,000 cycles
Seal: IP64 or IP68S
Operating Temp Range: -40°C to +85°C
Operating Force: Standard: 1.7 lbs. +/- 0.5 lb.
Low Force: 12 oz +/- 4 oz
Total Travel: 0.080 inches max
